Product Description
Double Flanged Pallet Support - Ship from California
Double flanged pallet supports are engineered to provide support for pallets stored on pallet rack beams. They neatly fit into the standard 1-5/8” step of pallet rack beams, with tabs at the ends of the pallet support flanging over the front and back of the beam. This flange design ensures a secure placement of the pallet support, minimizing the risk of supports dislodging.
Among our range of pallet supports, those with flanges are particularly favored for their straightforward drop-in installation. The flanged pallet supports feature a hole at the end of the flange, allowing for additional support by tek screwing them into the beams.
Flanged pallet supports are well-suited for providing bottom support to pallets stored in a selective pallet racking system. They represent a cost-effective solution for supporting full pallet loads within a selective pallet rack setup.
Dimensions:
- Length: 36”, 42”, 48”
- Capacity: 1122 lbs, 1300 lbs and 1545 lbs
*For Bolted Pallet Racking ONLY Will Not Fit Welded Pallet Racking
