Lineshaft Conveyor Curves
These lineshaft conveyor curves are the means in which product changes direction in a lineshaft conveyor system. Used in combination with lineshaft drives, these curves are available in several widths with either a 45º or 90º turn. Lineshaft curve units must be 'slaved' to a drive unit in order to operate.
How does lineshaft conveyor work?
Lineshaft powered roller conveyors are a truly innovative design among powered conveyors. The basic design utilizes rollers that are driven by a urethane belt from a drive shaft under the roller bed which runs the length of the conveyor. This driveshaft is turned by a motor and transmits its rotation via small urethane belts to individual rollers.
This type of conveyor also provides a basic accumulation function. When back-pressure is applied to the product being conveyed, the spools driving the rollers under the product will slip on the drive shaft providing very minimal back-pressure.
- 36" inside radius
- 2-1/2" diameter to 1-11/16" diameter zinc plated tapered rollers
- 7/16" hex, spring retained steel axles
- Sealed grease packed bearings
- Rollers set 1/4" high on 3" centers
- 5-1/2" x 1-1/2" x 12 gauge powder coated formed steel channel frames
- Bolted construction
- Includes one H-style leg support - 30" to top of roller
*Stand-alone components require an additional support. Please call for more information.
*Product may vary slightly from photos. Pricing & availability is subject to change without notice.
