Product Description
Heavy Duty Series Manual Pallet Jack
The AC66 Heavy Duty Series Manual Pallet Truck has a 6,600 lb. load capacity and is used for heavy duty/robust applications. It is the ideal choice for manual material transportation over short distances in stores, hospitals, institutions, offices, warehouses, and factories.
This ergonomic, powder-coated pallet truck offers reliable, sturdy, torsion-resistant operation due to its extremely strong, high quality steel profile. It is easy to maneuver with effortless steering. Chromed bearing bushings and joints ensure quiet operation and a long life. High-quality with a great price.
Product Videos
Specifications
Unit type
Manual pallet truck
Load capacity
6,600 lb.
Fork dimensions
27"W x 48"L standard
Fork size
6.3" x 2.4"
Maximum fork height
7.5"
Minimum fork height
2.95"
Steering wheel
7" x 2"
Load roller
Single 2.9" x 3.7"
Features
Ergonomic handle with comfortable rubber grip
Handle offers optimized safety and comfort. Three position operational handle lever for lifting, transportation, and lowering purposes.
Lower position
To lower load, pull up on the fingertip control.
Neutral position
Place fingertip control in this position when pulling the truck load.
Lift position
To raise load, push down on fingertip control, pump handle to raise the load.
Galvanized one-piece integrated hydraulic pump
With overload relief valve
Axle-mounted, 3-position loop handle (up/down/neutral)
Adjustable push rod assembly
Fork tip entry/exit roller
180° operations arc
Articulation steer axle
