Product Description
Anchors - Stong Bolt 2
Strong-Bolt® 2 Wedge Anchor
The Strong-Bolt® 2 Wedge Anchor is anchoring solution designed for heavy-duty applications in concrete. Featuring an enhanced wedge design, this anchor provides superior holding power, ensuring a secure and reliable installation in challenging environments.
Applications
- Fastening structural steel, and mechanical equipment, hand rails and racking systems: ( Check local building codes and or structural analysis for correct product selection. Some installations require additional heavier anchorage due toseismic or wind load considerations
Some typical options are:
- Conveyor Support: 3/8 x 3.75”
- Pallet Rack / Post Protectors: 1/2 x 4.75”
- Cantilever Rack 5/8 x 5”
- Aisle Guards: . x 5.5”
Product Videos
Specifications
Material: High-strength steel (carbon or stainless).
Coating: Zinc-plated or galvanized for corrosion resistance.
Thread Type: Standard UNC or Metric.
Head Type: Hex Head or Wedge Anchor.
Pull-Out Resistance: Depends on concrete type and embedment depth.
Torque Specification: 40-75 ft-lbs.
Features
Chamfered top designed to prevent mushrooming during installation
Code listed for cracked and uncracked concrete, and masonry applications
Qualified for static and seismic loading conditions (seismic design categories A through F)
Suitable for horizontal, vertical and overhead applications
Qualified for minimum concrete thickness of 3 1/4", and lightweight concrete-over-steel deck thickness of 2 1/2" and 3 1/4"
Standard (ANSI) fractional sizes: fits standard fixtures and installs with common drill bit and tool sizes
Tested per ACI355.2 and AC193
